Processor module：
| Jetson Xavier NX | Jetson Xavier NX 16GB | |
| AI Performance | 21 TOPS | |
| GPU | 384-core NVIDIA Volta ™ GPU with 48 Tensor Cores | |
| CPU | 6-core NVIDIA Carmel Arm®v8.2 64-bit CPU 6MB L2 + 4MB L3 | |
| Video Encode |
2x 4K60 | 4x 4K30 | 10x 1080p60 |22x1080p30 (H.265) 2x 4K60 | 4x 4K30 | 10x 1080p60 |20x108p30 (H.264) |
|
| Video Decode | 2x 8K30 | 6x 4K60 | 12x 4K30 | 22x1080p60 | 44x 1080p30 (H.265) 2x 4K60 | | |
| Memory | 8 GB 128-bit LPDDR4x59.7GB/s | 16 GB 128-bit LPDDR4x 59.7GB/s |
| Storage | 16 GB eMMC 5.1 * | |
|
Jetson NANO |
Jetson TX2 NX |
|
|
AI Performance |
472 GFLOPS |
1.33 TFLOPS |
|
GPU |
128-core NVIDIA Maxwell™ architecture GPU |
256-core NVIDIA Pascal™ architecture GPU |
|
CPU |
Quad-Core Arm® Cortex®-A57 MPCore processor |
Dual-Core NVIDIA Denver 2 64- Bit CPU and Quad-Core Arm® Cortex®-A57 MPCore processor |
|
Video Encode |
1x 4K30 (H.265) 2x 1080p60 (H.265) |
1x 4K60 (H.265) 3x 4K30 (H.265) 4x 1080p60 (H.265) |
|
Video Decode |
1x 4K60 (H.265) 4x 1080p60 (H.265) |
2x 4K60 (H.265) 7x 1080p60 (H.265) 14x 1080p30 (H.265) |
|
Memory |
4GB 64-bit LPDDR4 25.6GB/s" |
4GB 128-bit LPDDR4 51.2GB/s |
|
Storage |
16 GB eMMC 5.1 * |
16 GB eMMC 5.1 |
Product specification：
| Interface |
Specification |
| Network | 1 × Gigabit Ethernet Connector (10/100/1000) |
| USB |
2x USB 3.0 Type A (Integrated USB2.0)1X USB 3.0 1x USB 2.0 Micro-AB |
| Video
output |
1✖HDMI |
| SIM Card | 1x SIM Card |
| CAN | 1 × CAN |
| RS232 | 1x RS232 |
| TF_Card | 1xTF_Card |
| Function key | 1xReset key; 1x Recovery key |
| Project |
Specification |
| Input Voltage | +9V to +19V DC Input @ 3A |
| Load capacity | Above 60W |
|
Dimensions (W×D ×H) |
94x92x51 (mm) |
|
Operating Temperature |
-25℃-65℃ 0.2~0.3m/airflows |
|
Storage Temperature |
-20℃-60℃ |
| Weight |
0.390KG |
Schematic diagram of dimensions：
| Front view | Left view |
 |
 |
| Up view | Right view |
 |
 |
