| Module Compatibility | Jetson Orin NX/Orin Nano |
| Display | 1x HDMI |
| Ethernet | 5x Gigabit Ethernet (10/100/1000) |
| USB | 4x USB 3.0 Type A (Integrated USB 2.0) 1x USB 2.0+3.0 Type C USB 2.0+3.0ZIF 20P 0.5mm pitch 1x USB 2.0（1.25MM.CON） |
| M.2 KEY M | 1x M.2 KEY M Interface |
| M.2 KEY E | 1x M.2 KEY E Interface |
| I2C | 1 x I2C |
| Camera | 120P camera interface |
| FAN | 1xFAN(5V PWM) |
| Audio Output | 1 x 3.5 Headphone holder 2 x Speaker |
| Multi functional seat | 1x I2C Link（+3.3V I/O） 1 x RS232;1 x RS485 1x CAN, 1CAN（Receiver and transceiver） 1 x UART 1 x GPIO 1X SPI Bus(+3.3V Level |
| LED status indicators | 4x LED STATE |
| DC | Power interface |
| Input Voltage | +12--+36VDC Input NO PSE Device（Max 80W）， ith PSE Device(Max 150W） |
| Load capacity | Above 90W |
| Dimensions (W×D ) | 183x122 (mm) |
| Operating Temperature | -25℃-70℃ |
| Storage Temperature Humidity | -25℃-65℃, 10% -90% Non condensation environment |
